The STYLE 350 lathe is ideal for machining single pieces and small series. A heavy cast iron frame gives the machine a very solid base. The ergonomic design combines optimal accessibility and ease of use with sufficient safety. This machine offers you all the flexibility you want for turning the most diverse products.
Very accurate machining with the STYLE 350 CNC lathe
One of the smaller lathes from the STYLE lathes series is also equipped with the unique STYLE control. The lathe is equipped with the latest STYLE control, which speeds up the machining process of your products considerably and also makes high-quality products. Naturally you will bring a very stable CNC lathe to your machine park with this machine. Due to the flatness of the bed width (305 mm) and the center, you can assume that this machine is very stable, so that your products can be accurately produced.
Programming from the office
You can place all your programs that you want to run on a USB stick, but it is also possible to place the computer of the lathe in your network. This allows you to program your programs outside the machine.
Machine
Swing over bed mm 380
Swing over support mm 190
Distance between centers mm 850
Bed width mm 305
Maximum weight between centers kg 300
Main spindle
Main motor power (S6) kW 5.5 / 7.5 / 11
Spindle bore ø mm 54
Maximum spindle speed rpm 3000 / 4000
Spindle taper D1-6
X- and Z- axis
Rapid movement m/min 8
Feed rate m/min 2
Tail stock
Quill ø mm 54
Quill stroke mm 100
Quill taper MT 4
Chuck size 6/8/10 inch
Max Turning dia 14.96 inch
Max Turning Length 33.46 inch
Bar Capacity 2.13 inch
General
Weight kg 2000
Machine dimensions (l/w/h) m 2.5 x 1.8 x 1.8
