The STYLE MC series are the right machining centers for the demanding machine operators. Machining centers are known for their wide working range and versatility when it comes to machining parts. These machining centers are suitable for single pieces and small series. The STYLE MC 350 is a CNC controlled machine equipped with our very accessible STYLE CNC control system with a clear view of the drawing and product.
STYLE MC 350 machining center at a glance:
• Class C3 prestressed ball screws prevent thermal expansion for high milling accuracy
• The X / Y / Z axis is driven directly by the axis motors, which ensures high positioning
• Stroke X-axis: 350 mm, Stroke Y-axis: 210 mm, Stroke Z-axis: 340 mm
• Table size 810 x 250 mm
• 0 – 8000 rpm at 3.7 kW
The machining center with very accessible controls
The MC 350 machining center is equipped with a very stable cast iron frame with linear guides. The machine was built and designed by real Dutch machine builders. The machining center MC series is a line of closed, compact milling machines with an X stroke of 350 mm respectively, a modern CNC machine for the production and flexible machining of parts. The control system offers novice machineries the accessibility to get started with just a few hours of training and the experienced operator the tools to make high-quality complex products.
Programming from the office
You can place all your programs that you want to mill on a USB stick, but it is also possible to place the computer of the milling machine in your network. This allows you to program your programs outside the machine.
X-axis movement mm 350
Y-axis movement mm 210
Z-axis movement mm 340
Table size mm 810 x 250
Maximum table load kg 80
Height work table mm 850
Distance spindle nose to work table mm 50 – 390
Distance spindle nose to column mm 260
Main spindle
Main motor power (S6) kW 3.7 / 5.5
Maximum spindle speed rpm 8000
Spindle taper BT – 30 SK/DIN698711
X-, Y- and Z- axis
Rapid movement m/min 15
Feed rate m/min 10
Tool changer
Automatic tool changer # 8
General
Weight kg 1400
Machine dimensions (l/w/h) m 1.4 x 1.4 x 2.0
